PHATSAT

RG6 EX6XLPLUS Signal Tight Compression Drop Connectors Nickel-Plated Brass Construction 21mm Stroke Length

RG6 EX6XLPLUS Signal Tight Compression Drop Connectors Nickel-Plated Brass Construction 21mm Stroke Length

Regular price $5.50
Regular price Sale price $5.50
Sale Sold out
Quantity
  • Male F-type to Male F-type coaxial connector
  • Uses the dynamic range of the tough yet versatile plastic body to seal in the most effective way possible.
  • Metal compression ring also allows industry leading cable retention values through all cable sizes in the field
  • Bandwidth 0 MHz to 3 GHz
    Impedance 75 Ohms (nominal)
    Return Loss (Gated)
    5 to 1,000 MHz -30 dB Minimum
    1,000 to 2000 MHz -30 dB Minimum
    2,000 to 3,000 MHz -20 dB Minimum
    Insertion Loss 5 to 3,000 MHz Less than .20 dB
    Operating Temperature -40 °F to 140 °F (-40 °C to 60 °C)
    Cable Retention 45 lbs (20.41 kg) minimum
  • Constructed with Brass, Nickel Plated, Anti-Corrosion Materials
  • Excellent Shielding Protection
  • Unique 7/16 in nut profile allows hand tightening while discouraging wrench-tightening on CPEs
  • Maintains ground continuity even when very loose
  • Reduces QAM errors/packet loss
  • Prevents service issues from loose connections


*** ***
